Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-63
Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-28 Induction motor 1PH7135-NF
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
18.5 1500 118 42 8000 30 0.109 130
0
4
8
12
16
20
24
28
32
36
40
0 1000 2000 3000 4000 5000 6000 7000 8000
S6–25% (67.0 A)
S6–40% (58.0 A)
S6–60% (50.0 A)
S1 (42.0 A)
continuous
briefly
0
20
40
60
80
100
120
140
160
180
200
0 1000 2000 3000 4000 5000 6000 7000 8000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (118 Nm, 42.0 A)
S6–60% (146 Nm, 50.0 A)
S6–40% (178 Nm, 58.0 A)
S6–25% (210 Nm, 67.0 A)
continuous
briefly
Fig. 2-25 1PH7135–NF
