Siemens Simodrive 1PH7 - Page 84

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-84
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-49 Induction motor 1PH7167-NF-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
37 1500 236 82 8000 35 0.23 228
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
0 1000 2000 3000 4000 5000 6000 7000 8000
S6–25% (134.0 A)
S6–40% (115.0 A)
S6–60% (97.0 A)
S1 (82.0 A)
continuous
briefly
M [Nm] P [kW]
n [RPM]
0
50
100
150
200
250
300
350
400
450
0 1000 2000 3000 4000 5000 6000 7000 8000
n [RPM]
S1 (236 Nm, 82.0 A)
S6–60% (293 Nm, 97.0 A)
S6–40% (357 Nm, 115.0 A)
S6–25% (427 Nm, 134.0 A)
continuous
briefly
Fig. 2-46 1PH7167-NF-0L
