Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-91
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-56 Induction motor 1PH7184-NL
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
78 2500 298 172 5000
7000
1)
40 0.5 390
0
10
20
30
40
50
60
70
80
90
100
110
120
0 1000 2000 3000 4000 5000 6000 7000
S6–40% (237.0A)
S6–60% (204.0A)
S1 (172.0A)
P [kW]
n [RPM]
0
50
100
150
200
250
300
350
400
450
500
0 1000 2000 3000 4000 5000 6000 7000
n [RPM]
M [Nm]
continuous
briefly
2)
S1 (298 Nm, 172.0 A)
S6–60% (371 Nm, 204.0 A)
S6–40% (439 Nm, 237.0 A)
continuous briefly
2)
Fig. 2-53 1PH7184-NL
____________
1) Optional
2) This only applies for bearing versions for coupling/belt out-drive.
For bearing versions designed for increased cantilever forces, this limit is at n=3000 RPM
For bearing versions designed for increased maximum speeds, this limit is at n=4500 RPM
