Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-97
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-62 Induction motor 1PH7224-NF
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
100 1500 637 188 4500
5500
1)
40 1.48 650
S6–60% (802 Nm, 230.0 A)
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500
Influence of the pulse frequency f
p
f
p
I
N
P
N
L
A
[kHz]
[A]
[kW]
[dB (A)]
3.2
188
100
81
4
180
98
76
4.7
162
85.5
76
Tolerance +3 dB(A)
S6–40% (248.0 A)
S6–60% (230.0 A)
S1 (188.0 A)
P [kW]
n [RPM]
0
100
200
300
400
500
600
700
800
900
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500
n [RPM]
M [Nm]
continuous
briefly
2)
S1 (637 Nm, 188.0 A)
S6–40% (866 Nm, 248.0 A)
continuous
briefly
2)
Fig. 2-59 1PH7224-NF
____________
1) Optional
2) This only applies for bearing versions for coupling/belt out-drive.
For bearing versions designed for increased cantilever forces, this limit is at n=2700 RPM
For bearing versions designed for increased maximum speeds, this limit is at n=3600 RPM
