Dimension Chart for Drive Drawings
Module Type Module Rating Module
Width
dim. X dim. Y dim. Z Weight kg(lb's)
Power Infeed (I/R & U/E)
5 KW 50 mm - - - 6.5 (14.3)
(6SN1145- & / or 6SN1146-)10, 16 KW 100 mm 50 mm - - 9.5, 10.5 (21, 23)
28, 36 KW 200 mm 150 mm - - 15.5 (34)
55, 80, 120 KW 300 mm 250 mm 100 mm 50 mm 26,26,29 (57,57,64)
Monitoring & Pulsed
Resistor
All 50 mm - - -
(6SN1112- & / or 6SN1113-)
Power Modules (1 Axis)
6SN1123 - 1AA0_ - 0HA1, 0AA1,
0BA1, 0CA1
50 mm - - - 7.5 (17)
" 0DA1 100 mm 50 mm - - 9.5 (21)
" 0EA1, 0LA1 150 mm 100 mm - - 13 (29)
" 0FA1, 0JA1, 0KA1300 mm 250 mm 100 mm 50 mm 26,21,24 (57,46,53)
Power Modules (2 Axis)
6SN1123 -1AB0_ - 0HA1, 0AA1,
0BA1
50 mm - - - 7 (15.4)
" 0CA1 100 mm 50 mm - - 13.5 (30)
1-162
