Siemens SIMOTICS S-1FT2 User Manual

You can 󹪝nd possible combinations in the relevant catalog.
Please note that not every theoretical combination is possible.
Description Position in the article number
 1 2 3 4 5 6 7 - 8 9 1
0
11 12 - 13 14 15 16
SIMOTICSS-1FT2 synchronous servomotors 1 F T 2              
Version/inertia

High Dynamic 1
Compact 2
Frame size / shaft height SH30 0 3
SH40 0 4
SH50 0 5
SH 63 0 6
SH 80 0 8
SH 100 1 0
Overall length 0 ... 8 - ☐
Cooling Natural cooling A
Forced ventilation S
Rated speed 1500r/min @ 400V B
2000r/min @ 400V C
2500r/min @ 400V E
3000r/min @ 400V F
4500r/min @ 400V H
6000r/min @ 400V K
Holding brake None 0
with 1
Reinforced brake 2
Degree of protection IP64 0
IP65 with radial shaft seal ring without spring 1
IP67 with radial shaft seal ring 2
Shaft geometry Plain shaft (without keyway) 0
Shaft with feather key 1
Plain shaft, alternative shaft geometry
(11mm x 23mm)
0 3  0  2
plain shaft, alternative shaft geometry
(14mm x 30mm), only for 1FT2☐04
0 4  0  2
Encoder Absolute encoder, singleturn, 22-bit (encoder AS22DQC) S
Absolute encoder singleturn, 26-bit (encoder AS22DQC) B
Absolute encoder 22-bit + 12-bit multiturn (encoder AM22DQC) M
Absolute encoder, 26-bit + 12-bit multiturn (encoder AM26DQC) C
Connection system 2CC (two cable system) for S120 B
Version number Start 0
Description of the motors
3.2Structure of the article number
SIMOTICS S-1FT2 synchronous motors for SINAMICS S120
36 Operating Instructions, 12/2023, A5E50610821B AF
