Description of the planetary gearbox
2.3 Properties of planetary gearboxes
Planetary gearboxes for servomotors
24 Operating Instructions, 09/2020, A5E50494253B AA
2.3 Properties of planetary gearboxes
This chapter describes the mechanical properties of the planetary gearboxes and the
materials used.
The mounting position of the planetary gearbox is not specified.
Property of the planetary gearbox
Gearbox input and output rotate in the same direction as the motor
Lubricated for life in the factory
Any mounting position is possible
Materials used for the gearbox
Gearbox housing (gearing
area)
Mounting flange (machine
side)
