Planetary gearboxes for servomotors
Operating Instructions, 09/2020, A5E50494253B AA
63
Technical data and dimension drawings
10.1 Technical data for servomotors with planetary gearbox
The technical data for the motors with the various shaft heights is provided in the "Technical
data and characteristic curves" chapter of the Configuration Manual for the specific motor.
Carefully note that the rated operating points and S1 data can change when a gearbox is
mounted onto the motor.
Adapt the values for operating the motors according to Chapter "Derating factors" for the
specific motor.
Dimension sheets and 3D CAD files for the motors with planetary gearboxes are provided in
the DT Configurator in the Internet at DT CONFIGURATOR (http://siemens.de/dt-konfigurator
).
