Description of the planetary gearbox
2.5 Rating plate data
Planetary gearboxes for servomotors
Operating Instructions, 09/2020, A5E50494253B AA
27
Table 2- 2 Description of the rating plate data
Position Description / technical data
Characteristic value
1F☐2
1F☐7
1
Article number
2
ID No., serial number
3
Order codes as a supplement to the article number
4
Type and size of the planetary gearbox
5
Transmission ratio of the planetary gearbox
i
6
Max. output speed of the gearbox
n2max
7
Maximum output torque of the geared motor
N2max
8
Geared motor static torque
M
2.0
of the geared
motor
(gearbox output side)
M
0
of the motor (S3-
60 % operation)
9
Geared motor rated torque
M
2N
of the geared
motor
(gearbox output side)
M
N
of the motor (S3-
60 % operation)
10
Induced voltage at rated speed
UIN
11
Geared motor weight
m
12
Encoder type identifier
13
Holding brake data: Type, voltage, power consumption, holding
torque (when installed)
14
Space for customized labeling
15
Manufacturer's address
16
Stall current
I0
17
Short-time permissible maximum motor current
Imax
18
Degree of protection
19
Cooling method according to EN 60034-6
20
Temperature class of the insulation system
21
Revision version
22
Rated motor speed
n
2N
of the geared mo-
tor
n
N
of the basic motor
23
Maximum motor speed
n1max (matched to the gearbox)
24
Certifications
25
Standard for all rotating electrical machines
26
Permissible mounting position
27
Data matrix code
