Entry Meaning Remedy
Non-volatile data loaded from the backup
file
(Persistent Data Backup File Loading
done)
Non-volatile SIMOTION data has
been successfully restored from the
backup
copy of the backup file on the
CF card.
-
Error while loading non-volatile data from
a file
(Persistent Data File Loading failure)
Backup file or backup copy could not
be loaded.
Possible causes:
●
Backup file or backup copy not
available
● Invalid data in backup file
Use the _savePersistentMemoryData
system function to generate a backup
file with valid contents.
Device with battery module Fan/battery module is present. -
Device without battery module Fan/battery module is not present. Connect fan/battery module
Module replacement detected - NVRAM
has been initialized
A module replacement has been de‐
tected
on the basis of the serial num‐
ber.
The non-volatile SIMOTION data on
the controller will be deleted and the
data from the CF card transferred to
the controller.
-
Module replacement not detected -
NVRAM has not been initialized
An error has occurred. The non-vola‐
tile
SIMOTION data on the controller
will not be deleted.
Possible causes:
● Incorrect controller type
● File system of the CF card corrupt
1)
These warnings are only signaled when the fan/battery module has been inserted.
Refer
to the SIMOTION SCOUT Configuration Manual for how to read out the contents of the
diagnostic buffer.
Evaluating via PeripheralFaultTask
Battery state changes in RUN are reported to the user program by calling PeripheralFaultTask.
Changes can be evaluated there using Taskstartinfo:
● TSI#InterruptId = _SC_PC_INTERNAL_FAILURE (= 205)
● TSI#details = 16#00000040
If no battery is used during the transition of the operating state to RUN, no PeripheralFaultTask
will be triggered (application case: D4x5‑2 should generally be operated without a battery).
References
You will find detailed information on setting up Taskstartinfo (#TSI) in the SIMOTION Runtime
Basic Functions Function Manual.
Commissioning (hardware)
5.3 User memory concept
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B 111
