Introduction
1.8 Parameterizing the digital outputs
Application document for functional safety STO, SS1 (ISO 13849-1)
Compact User Manual, 09/2016, A5E34871844AM
17
1.8
Parameterizing the digital outputs
In order to signal to the safety relay that the drive E-STOP function has been activated, the
following parameters must be set at the SINAMICS DC MASTER:
Digital output DO3 at connector X177.22 controls relay K
EP
. This serves as feedback signal
contact for the E-STOP path.
The function of DO3 (connector X177.22) is defined using parameter p50774:
p50774 = (63) r53100.0
Digital output DO2 at connector X177.21 controls, via relay K
DO2F
, the field contactor.
The function of DO2 (connector X177.21) is defined using parameter p50773.
The setting of p50773 is dependent on the setting of parameter p50082:
p50082 = 0
(no field)
p50773 = 0
p50082 = 1
(field is also switched with the armature contactor)
p50773 = (63) r53082.0
p50082 = 2
(standstill field at ≥ o7.0)
p50773 = 1
p50082 = 3
(field is permanently switched on)
p50773 = 1
p50082 = 4
(field is also switched with the auxiliaries ON si
g-
nal)
p50773 = (63) r53
210.2
p50082 = 21
(external field power unit, otherwise, as for setting
1)
p50773 = (63) r53082.0
p50082 = 22
(external field power unit, otherwise, as for setting
3)
p50773 = 1
p50082 = 23
(external field power unit, otherwise, as for setting
3)
p50773
= 1
p50082 = 24
(external field power unit, otherwise, as for setting
4)
p50773 = (63) r53210.2
Note
(63) signifies: "from own drive object"
r53100.0 is E
-Stop state (1 = no E-Stop, 0 = E-Stop)
r53082.0 is CLOSE armature contactor
r53210.2 is
auxiliaries ON
Note
The maximum 100 mA current rating of the digital outputs must be carefully observed.
