3.1 Wiring
The figure below shows the hardware setup of the application.
Figure 3-1: Wiring
L1
L2
L3
N
PE
M
Y
L1 L2 L3 PE
U2 V2 W2 PB
L+ M PE L1 N PE L+ M
PB LAN
LAN M L+
24 V DC
SINAMICS
G120C DP
SIMATIC Panel
KTP600
SIMATIC S7
CPU 1212C
Note
Note the setup guideline in the manuals of the respective devices (see /1/, /4/, /6/).
