4 Operating the Application
4.3 Monitoring and parameter access via operator panel
SINAMICS G120 DP at S7-1200
Entry-ID: 70155469, V1.4, 07/2018
Copyright Siemens AG 2018 All rights reserved
4.3.3 Parameter access
Reading/writing parameters
Figure 4-6: Reading/writing parameters
Table 4-3: Instructions – writing/reading parameters
Select the access type with the
“Read parameters” and “Write
parameters” buttons.
The selected access type is displayed via
a bright green button.
Read parameters:
Proceed with point 3 in the table.
Write parameters:
When tapping or clicking the yellow
input fields for the ramp-up/ramp-
down time, a keyboard mask for the
value input opens. Finish your input
with the Return key.
8,0
Ramp up time
Ramp down time
