10.6.6 Specific technical data, 400 V inverters
Table 10-50 PM240-2, IP20, Frame Size A, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1PE11-8UL1
6SL3210-1PE11-8AL1
6SL3210-1PE12-3UL1
6SL3210-1PE12-3AL1
6SL3210-1PE13-2UL1
6SL3210-1PE13-2AL1
LO base load power 0.55 kW 0.75 kW 1.1 kW
LO base load input current 2.3 A 2.9 A 4.1 A
LO base load output current 1.7 A 2.2 A 3.1 A
HO base load power 0.37 kW 0.55 kW 0.75 kW
HO base load input current 2.0 A 2.6 A 3.3 A
HO base load output current 1.3 A 1.7 A 2.2 A
Fuse according to IEC
Fuse according to UL, class J
3NA3805 (16 A)
10 A
3NA3805 (16 A)
10 A
3NA3805 (16 A)
15 A
Power loss 0.04 kW 0.04 kW 0.04 kW
Required cooling air flow 5 l/s 5 l/s 5 l/s
Weight without filter 1.3 kg 1.3 kg 1.3 kg
Weight with filter 1.5 kg 1.5 kg 1.5 kg
Table 10-51 PM240-2, IP20, Frame Size A, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1PE14-3UL1
6SL3210-1PE14-3AL1
6SL3210-1PE16-1UL1
6SL3210-1PE16-1AL1
6SL3210-1PE18-0UL1
6SL3210-1PE18-0AL1
LO base load power 1.5 kW 2.2 kW 3.0 kW
LO base load input current 5.5 A 7.7 A 10.1 A
LO base load output current 4.1 A 5.9 A 7.7 A
HO base load power 1.1 kW 1.5 kW 2.2 kW
HO base load input current 4.7 A 6.1 A 8.8 A
HO base load output current 3.1 A 4.1 A 5.9 A
Fuse according to IEC
Fuse according to UL, class J
3NA3805 (16 A)
20 A
3NA3805 (16 A)
30 A
3NA3805 (16 A)
30 A
Power loss 0.07 kW 0.1 kW 0.12 kW
Required cooling air flow 5 l/s 5 l/s 5 l/s
Weight without filter 1.4 kg 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg 1.6 kg
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
488 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
