Siemens SINUMERIK 808D ADVANCED Training Manual

808D ADVANCED Page 41 Programming and Operating — Turning
Create Part
Program
Part 2
s
The easiest way to
cut a thread is to
use CYCLE99
The cycle can be
found and
parameterized
with the “Turn.” SK.
The relevant cycle
can now be found
using the vertical
SKs on the right.
Select “Thread”
and “Thread long.”
using the vertical
SKs and param-
eterize the cycle
according to re-
quirements.
With the “OK” SK, the setting is activated and the
selected cycle and data will be transferred to the part
program automatically as shown below.
The machine will cut a thread at the position
specified in the cycle.
Thread
cutting
→
BASIC THEORY
