Programming and Operating — Turning Page 44 808D ADVANCED
Create Part
Program
Part 2
s
N420 CYCLE82( 5.00000, 0.00000, 2.00000, -20.00000, 0.00000, 0.50000)
With the “OK” SK, the setting is activated and the
selected cycle and data will be transferred to the part
program automatically as shown below.
If there is no other operation, the machine will drill holes
at the current position.
The easiest method
to drill holes is with
CYCLE81/82: With-
out/with dwell at
current hole depth.
CYCLE83：Each
drilling operation
needs a withdrawal
distance during deep
hole drilling.
The cycle can be
found and
parameterized with
the “Drill.” SK.
Select “Center drill-
ing” using the vertical
SKs ,and then select
“Center drilling” and
parameterize the
cycle according to
requirements.
Drilling
holes
For RTP, RFP, SDIS, DP, DPR and DTB and related commands, see page 50
→
The relevant cycle
can now be found
using the vertical
SKs on the right.
