808D ADVANCED Page 45 Programming and Operating — Turning
Create Part
Program
Part 2
s
With the “OK” SK, the setting is activated and the
selected cycle and data will be transferred to the part
program automatically as shown below.
If there is no other operation, the machine will drill
holes at the current position.
The easiest way to
tap a hole is to use
CYCLE84: Solid
tap holder
CYCLE840: With
floating tap holder.
The cycles can be
found and
parameterized
using the “Drill.”
SK.
The relevant cycle
can now be found
using the vertical
SKs on the right.
Select “Thread”
using the vertical
SKs and then
select “Rigid tap-
ping.” and param-
eterize the cycle
according to
requirement.
Tapping
→
BASIC THEORY
