Siemens SINUMERIK 840D sl Ctrl-Energy User Manual

Data block
DB9907
Name: Sentron‐
Pac
Signal
direction
Meaning Symbol Format
DB9907.DBX0.0 PLC -> HMI Display manual value ManualVal BOOL
DB9907.DBX0.1 PLC -> HMI SENTRON PAC rep‐
resents the complete
machine
SentronPacMach BOOL
DB9907.DBX0.2 PLC -> HMI Imported active ener‐
gy is read from SEN‐
TRON PAC
FeedInEnergyReadSP BOOL
DB9907.DBX0.3 PLC -> HMI Exported active ener‐
gy is read from SEN‐
TRON PAC
FeedBackEnergyReadSP BOOL
DB9907.DBX1.0 PLC -> FW Measuring request to
PLC FW
MeasAuto BOOL
DB9907.DBX2.0 HMI -> FW Measurement is run‐
ning
MeasAct BOOL
DB9907.DBD4 PLC -> HMI Manual value ManualValue REAL
DB9907.DBD8 FW -> HMI Total active
power
ActivePowerItem REAL
DB9907.DBD12 MeasAuto
== 0:
PLC -> HMI
MeasAuto
== 1:
FW -> HMI
Measured imported
active energy tariff1
ActiveEnergyItem REAL
DB9907.DBD16 MeasAuto
== 0:
PLC -> HMI
MeasAuto
== 1:
FW -> HMI
Measured exported
active energy tariff1
ReactiveEnergyItem REAL
DB9907.DBD20 PLC -> FW Total active
power
in watts from SEN‐
TRON
ActivePowerSentron REAL
DB9907.DBD24 PLC -> FW Imported active ener‐
gy at tariff 1 (F) in Wh
from SENTRON
ActiveEnergySentron REAL
DB9907.DBD28 PLC -> FW Exported active ener‐
gy at tariff 1 (F) in Wh
from SENTRON
ReactiveEnergySentron REAL
DB9907.DBD32 FW -> HMI Imported active ener‐
gy in kWh current day
to HMI
ActiveEnergyDay REAL
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
30 System Manual, 01/2015, 6FC5397-0EP40-5BA2
