DB9907
Name: Sentron‐
Pac
Signal
direction
Meaning Symbol Format
DB9907.DBD36 FW -> HMI Exported active ener‐
gy in kWh current day
to HMI
ReactiveEnergyDay REAL
DB9907.DBD40 FW -> HMI Imported active ener‐
gy in kWh previous
day to HMI
ActiveEnergyPrevDay REAL
DB9907.DBD44 FW -> HMI Exported active ener‐
gy in kWh previous
day to HMI
ReactiveEnergyPrevDay REAL
DB9907.DBD48 FW -> HMI Imported active ener‐
gy in kWh month to
HMI
ActiveEnergyMonth REAL
DB9907.DBD52 FW -> HMI Exported active ener‐
gy in kWh month to
HMI
ReactiveEnergyMonth REAL
DB9907.DBD56 FW -> HMI Imported active ener‐
gy in kWh previous
month to HMI
ActiveEnergyPrevMonth REAL
DB9907.DBD60 FW -> HMI Exported active ener‐
gy in kWh previous
month to HMI
ReactiveEnergyPrevMonth REAL
DB9907.DBD64 FW -> HMI Imported active ener‐
gy in kWh year to HMI
ActiveEnergyYear REAL
DB9907.DBD68 FW -> HMI Exported active ener‐
gy in kWh year to HMI
ReactiveEnergyYear REAL
DB9907.DBD72 FW -> HMI Imported active ener‐
gy in kWh previous
year to HMI
ActiveEnergyPrevYear REAL
DB9907.DBD76 FW -> HMI Exported active ener‐
gy in kWh previous
year to HMI
ReactiveEnergyPrevYear REAL
Note
Evaluation of the energy consumption of the complete machine
If you have installed SENTRON PAC in the main circuit of the machine or SENTRON PAC
evaluates the energy consumption of the complete machine, set bit DB9907.DBX0.1 to 1.
As a consequence, in the display for Ctrl-E Analysis, the line "SentronPAC" is removed and
the measured value of the SENTRON PAC is entered into the line "Total machine".
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
System Manual, 01/2015, 6FC5397-0EP40-5BA2 31
