The R parameters are found under the identifier "/Channel/Parameter/R", which is eventually
mapped to "/Channel/Parameter/R[u1, 1]". If you want to access other parameters, you must
correspondingly extend the identifier, e.g. "/Channel/Parameter/R[u2, 56]".
Table 5-1 Examples of variable paths (NC access operations)
Variable path Description
/Channel/Parameter/R[u1,10] R parameter 10 in channel 1
/Channel/Parameter/R[u1,1,5]
/Channel/Parameter/R[u1,1,#5]
R parameter array
R parameters 1 to 5 in channel 1
/Channel/GeometricAxis/name[u2,3] Name of the 3rd axis in channel 2
/Channel/GeometricAxis/actToolBasePos[u1,3] Position of the 3rd axis in channel 1
5.3.2 Variable paths for GUD access operations
GUD variables can be found in the OPC UA server under the "/Sinumerik/GUD" node.
The displayed GUD variables always represent only the first parameter (for GUD arrays) of
the first NC channel (for channel-dependent GUD variables). If you want to access a different
parameter of a GUD array or a different channel, you must extend the identifier accordingly
for the NC access.
GUD arrays are 1-indexed for access, and access is always one-dimensional. This means,
the index must be calculated for multi-dimensional arrays.
Example 1: One-dimensional array, NC-global GUD array
"UGUD.DEF" file
DEF NCK INT ARRAY[2]
M17
Access is performed as follows:
ARRAY[0] → /NC/_N_NC_GD3_ACX/ARRAY[1]
ARRAY[1] → /NC/_N_NC_GD3_ACX/ARRAY[2]
Example 2: Two-dimensional array, channel-dependent GUD array
"UGUD.DEF" file
DEF CHAN INT ABC[3,3]
M17
Functionality
5.3 Variable access
SINUMERIK Integrate for Engineering Access MyMachine / OPC UA
Configuration Manual, 04/2018, 6FC5397-1DP41-0BA0 39
