Table 6-14 Assignment of connector X54
Pin Name Type Meaning
1 KT-OUT4 O Customer key 4 lamp
2 KT-OUT5 O Customer key 5 lamps
3 KT-OUT6 O Customer key 6 lamps
4 M V Ground
Interfaces for handwheels
Interface: Handwheel 1
Connector designation: X60
Connector type: 15-pole D-sub pin
Maximum cable length: 5 m
Table 6-15 Assignment of connector X60
Pin Name Type Meaning
1 P5HW V 5 V supply voltage
2 M V Ground
3 HW1_A I Handwheel pulses track A
4 HW1_XA I Handwheel pulses track A (negated)
5 N.C. - Not assigned
6 HW1_B I Handwheel pulses track B
7 HW1_XB I Handwheel pulses track B (negated)
8 N.C. - Not assigned
9 P5HW V 5 V supply voltage
10 N.C. - Not assigned
11 M V Ground
12 N.C. - Not assigned
13 N.C. - Not assigned
14 N.C. - Not assigned
15 N.C. - Not assigned
Interface: Handwheel 2
Connector designation: X61
Connector type: 15-pole D-sub pin
Maximum cable length: 5 m
Table 6-16 Assignment of connector X61
Pin Name Type Meaning
1 P5HW V 5 V supply voltage
2 M V Ground
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
Equipment Manual, 04/2021, A5E50753610B AA 43
