1 2 3 4 5 6 7 8 9 10 Meaning
on o o on o o o o Default device name: mcp-pn9
o o o on o o o o Default device name: mcp-pn8
on on on o o o o o Default device name: mcp-pn7
o on on o o o o o Default device name: mcp-pn6
on o on o o o o o Default device name: mcp-pn5
o o on o o o o o Default device name: mcp-pn4
on on o o o o o o Default device name: mcp-pn3
o on o o o o o o Default device name: mcp-pn2
on o o o o o o o Default device name: mcp-pn1
o o o o o o o o Default device name: mcp-pn
MCP set up as IE
A logical address can be assigned to the MCP for communication via Ethernet using the 10-bit
switch S2.
Table 6-20 Switch S2 is set as delivered
1 2 3 4 5 6 7 8 9 10 Meaning
o o
o o o o o o on on MPP address 192
The two switches S2-9 and S2-10 must remain OFF.
Switches S2-1 to S2-8 dene the MCP address in the range 0 to 255. Addresses 192 to 223 are
the default range. The MCP address is used as a reference for addressing an MCP during PLC
parameter assignment.
Table 6-21 Settings of switch S2
1 2 3 4 5 6 7 8 9 10 Meaning
o o
on on on on on on on on MPP address 255
x x x x x x x x "
on on on on on o on on MPP address 223
o on on on on o on on MPP address 222
on o on on on o on on MPP address 221
o o on on on o on on MPP address 220
on on o on on o on on MPP address 219
o on o on on o on on MPP address 218
on o o on on o on on MPP address 217
o o o on on o on on MPP address 216
on on on o on o on on MPP address 215
o on on o on o on on MPP address 214
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
