The switches S2-1 to S2-8 de󹪝ne the default device names.
Up to 128 default device names are supported. If these default device names are used, there is
no need to initialize the MPP.
Note
The default device names cannot be recon󹪝gured, e.g. through a STEP 7 "device initialization".
When you connect the MPP to a SINUMERIK control as a PROFINET component, make sure that
this functionality is supported by the relevant control.
DCP mode:
No default device name is available in this mode. The device name must be set by means of an
initialization procedure and remains saved on the MPP. It is deleted again if the factory setting
is restored, e.g. using STEP 7.
Table 6-19 Settings of switch S2
1 2 3 4 5 6 7 8 9 10 Meaning
on on
on on on on on on on on DCP mode
on on on on on on on o󹪜 Default device name: mcp-pn127
o󹪜 on on on on on on o󹪜 Default device name: mcp-pn126
on o󹪜 on on on on on o󹪜 Default device name: mcp-pn125
o󹪜 o󹪜 on on on on on o󹪜 Default device name: mcp-pn124
on on o󹪜 on on on on o󹪜 Default device name: mcp-pn123
o󹪜 on o󹪜 on on on on o󹪜 Default device name: mcp-pn122
on o󹪜 o󹪜 on on on on o󹪜 Default device name: mcp-pn121
o󹪜 o󹪜 o󹪜 on on on on o󹪜 Default device name: mcp-pn120
on on on o󹪜 on on on o󹪜 Default device name: mcp-pn119
o󹪜 on on o󹪜 on on on o󹪜 Default device name: mcp-pn118
on o󹪜 on o󹪜 on on on o󹪜 Default device name: mcp-pn117
o󹪜 o󹪜 on o󹪜 on on on o󹪜 Default device name: mcp-pn116
on on o󹪜 o󹪜 on on on o󹪜 Default device name: mcp-pn115
o󹪜 on o󹪜 o󹪜 on on on o󹪜 Default device name: mcp-pn114
on o󹪜 o󹪜 o󹪜 on on on o󹪜 Default device name: mcp-pn113
o󹪜 o󹪜 o󹪜 o󹪜 on on on o󹪜 Default device name: mcp-pn112
x x x x x x x x "
on on on on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn15
o󹪜 on on on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn14
on o󹪜 on on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn13
o󹪜 o󹪜 on on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn12
on on o󹪜 on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn11
o󹪜 on o󹪜 on o󹪜 o󹪜 o󹪜 o󹪜 Default device name: mcp-pn10
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
Equipment Manual, 04/2021, A5E50753610B AA 45
