Transport, storage and packing
9229 0025 176 0A 9
2019-08-05
• Hang the slinging gear only into the crane eyes.
• Transport the vacuum circuit-breaker to the mounting location or leave it sus-
pended from the crane for further work steps.
Keep the supplementary equipment on hand for installation.
Fig. 7 Transporting, only for 31.5 kA with distance
between pole centres 150/160
Fig. 8 Transporting, only for 24 kV with 2000 A /
2500 A
Note
Property damage due to incorrect fastening of the slinging equipment
The holders (49) will be damaged if ropes or similar slings are fastened below the
holders (49).
Only use the crane eyes to fasten the slinging equipment.
