Siemens SIPART DR19 User Manual

SIPART DR19
C73000-B7474-C140-06
53
Quick Reference Operating and Monitoring
The controller is to be switched from automatic to manual mode and the manip-
ulated value y then modified.
Method: modification of y
IF controller in manual mode AND y is displayed, THEN y can be modified.
actuating actuating
unit unit
down (up) up (down)
+
NOTE
The value of y can only be modified if the signal lamp "y external mode" (10) is
not on, i.e. the controller must not be in y external, tracking, safety or blocking
mode.
Example 3:
Modification
of y
M
e
th
o
d
:
T
og-
gling between
manual and
automatic
modes
permanent light
press
button (9)
1x
press
button (9)
1x
automatic mode
(11)
manual mode
w display
switched
(11)
permanent light
manual mode
(11)
OUT-Y
SP-W
actuating value y (2)
w
x
(7)
(8)
