SIPART DR19
C73000-B7474-C140-06
89
Quick Reference Program Controller
Only the special details of the program controller are given here; the operations of
parameterization and configuring and other display possibilities remain
unchanged! Controls by digital signals are not described.
5.3 CLPA - Clock Parameters
Setting the program-specfic parameters and functions for the program controller/
program set station.
(14) Signal lamp Program setpoint w
p
switched off via CB, clock stopped.
(15) Signal lamp "Internal setpoint" (clock stopped, setpoint adjustable)
(17) Signal lamp The complete program is -> 1 = PR1
shown here -> 2 = PR2
Step Procedure
1 Press button (6) about 5 sec until "PS" flashes. Release button -
"onPA" (selection level) displayed. Blocked if digital signals bLPS=1.
2 Press button (8) several times until "CLPA" is displayed (selection
level). Blocked if digital signal bLS=1.
3 Press button (9) about 3 sec until digital indicator SP-W (2) flashes
(configuring level). Controller now blocked and last value of y retained.
4 Using buttons (7) or (8) select parameter names in the SP-W (2)
digital indicator.
Quick step: Press one button after the other and remaining on both the
direction buttons (the first pressed determines the direction) parameters
will be let out in block at a time.
5 Press button (6) once, indicator PV-X (1) flashes, input field is
switched over.
6 Using buttons (7) or (8). Modify the parameter value in the PV-X
(1) indicator.
Quick step: see step 4.
7 Press button (6) once, indicator SP-W (2) flashes, input field is
switched back.
8 Repeat steps 4 to 7 until all necessary parameters are set.
9 Press button (13) once (selection level).
10 Press button (13) once (process control level). Controller is in manual
mode.
+
NOTE
For a program to be able to function, at least the PrSE, CLFO, t... and A...
parameters in the clock parameter list CLPA must be determined.
Configuring switches: S43 = 2, S23 = 8 (CB = "HIGH")
Function
Access to
the CLPA
function
Selecting and
changing
parameters
Exit to pro-
cess control
level
