Quick Reference Configuring
onPA - online parameters
1)
If S2=1: up to 9980 ms, minimum pulse interval and length;
with tA in cooling circuit, with tE in heating circuit.
Parameter Param-
name
Min Max Factory
setting
Eng.
unit
Filter time constant for xd filter
(adaptive)
Derivative action gain Vv
Proportional gain Kp
Integral action time Tn
Derivative action time Tv
Response threshold
Working point
Safety setpoint 1
Safety setpoint 2
Safety setpoint 3
Safety setpoint 4
tF
uu
cP
tn
tu
AH
Y0
SH1
SH2
SH3
SH4
off/1.000
0.100
0.100
1.000
off/1.000
0.0
Auto/0.0
-10.0
-10.0
-10.0
-10.0
1.000
10.00
100.0
9984
2992
10.0
100.0
110.0
110.0
110.0
110.0
1.000
5.000
0.100
9984
off
0.0
Auto
0.0
0.0
0.0
0.0
s
1
1
s
s
%
%
%
%
%
%
Start of manip. variable scale (YA<
YE)
Full scale of manip. variable
Heating period, y positioning time open
Cooling period, y positioning time closed
YA
YE
tP
tM
-10.0
-10.0
off/0.100
off/0.100
110.0
110.0
1.000
1.000
-5.0
105.0
1.000
1.000
%
%
s
s
Actuating pulse interval
Length of actuating pulse
tA
tE
20
20
600
1)
600
1)
200
200
ms
ms
Filter time AI1
Filter time AI2
Filter time AI3
t1
t2
t3
off/1.000
off/1.000
off/1.000
1.000
1.000
1.000
1.000
1.000
1.000
s
s
s
Constant c1
Constant c2
Constant c3
Constant c4
Constant c5
Constant c6
Constant c7
c1
c2
c3
c4
c5
c6
c7
-1.999
-1.999
-1.999
-1.999
-1.999
-9.99
+1.000
9.999
9.999
9.999
9.999
9.999
9.99
9.999
0.000
0.000
0.000
1.000
0.000
0.00
1.000
Display refresh rate dr 0.100 9.900 1.000 s
