SIPART DR19
92 C73000-B7474-C140-06
Explanation of abbreviations Quick Reference
1)
as of software version -B6
Subject Explanation see
RC
(RC
)
DO: Message "Computer mode of controller not
present"
StrS S60
Reset Function: Reset of time program, see also tS Program controler
page 87
Si DI: Switchover to safety manipulated variable YS StrS S26
StrS Configuring mode "Set configuring switches" Configuring page 55
tF Parameter: Filter time constant for filter xd (adaptive) onPA page 56
tS (tS
) DI: Switching off of setpoint ramp
When S1 = 5: Reset program run
1)
StrS S28
tSH DI: Hold setpoint ramp StrS S100
w
EA
Input: External setpoint as analog signal
(S1=2/3/4 and S93=2/3)
Input connections
page 83
w
ES
Input: External setpoint via interface
(S1 = 2/3/4/7 and S93 = 0/1/4/5)
Input connections
page 83
Y1 Parameter: Split range left, cooling
(two-position controller S2 = 1)
oFPA page 58
Y2 Parameter: Split range right, heating
(two-position controller S2 = 1)
oFPA page 58
YA Parameter: Lower limit of manipulated variable onPA
page 56 / S54
YE Parameter: Upper limit of manipulated variable onPA
page 56 / S54
yN Input: Tracking mode via analog input
Assignment of yN to AI1 to AI3
StrS S18
yR Input: External feedback for S controller,
y display for S controller
StrS S19/S55
YS Parameter: Safety manipulated variable (acts directly on DI Si) oFPA page 58
z Input: Disturbance variable z
(acts directly on manipulated variable y)
StrS S20
