1 Technical Description
1.6 Technical Data
1.6.3 Technical Data of the Options Modules
Manual
102
SIP ART DR24 6DR2410
C79000-G7476-C153-03
- Digital inputs
Signal status 0 ≤ 4.5 V or open
Signal status 1 ≥ 13 V
Input resistance ≥ 2.4 kΩ
Static destruction limit 35 V
6DR2801--8C 5BE 24 V Digital inputs BE5 to BE9 (slot 5),
BE10 to BE14 (slot 6)
Signal status 0
≤ 4.5 V or open
Signal status 1
≥ 13 V
Input resistance
≥27 kΩ
Staistical destruction limit ±35 V
6DR2802-8A 1AA(y
hold
) Analog outputs AA4 (slot 6), AA7 (slot 5)
- Analog output AA4/AA7
Rated signal range (0 to 100 %) 0 to 20 mA or 4 to 20 mA
Dynamic range 0 to 20.5 mA or 3.8 to 20.5 mA
Load voltage
for supply
from controller --1 to 18 V
by U
H
> 22.5V --1to15V
by U
H
=20V --1to12.5V
No load voltage ≤ 26 V
Inductive load ≤ 0.1 H
T ime constant 300 ms
Residual ripple 900 Hz ≤ 0.2 %
Resolution 0.1 %
Load dependence ≤ 0.1 %
Zero point error ≤ 0.2%
End value error ≤ 0.1 %
Linearity ≤ 0.05 %
Temperature influence
Zero point ≤ 0.1%/10k
End value ≤ 0.1%/10k
Static destruction limit --1 V to +35 V
- Digital output
St
Signal status 0 ≤ 1.5 V
Signal status 1 +19 to 26 V
Load current ≤ 30 mA, short--circuit--proof
Short--circuit current ≤50 mA clocking
Static destruction limit --1 to +35 V
- Auxiliary voltage U
H
Voltage range +20 to +30 V (including harmonic)
Current consumption
with supply from controller ≤ 6mA
with supply by U
H
≤ 70 mA
Static destruction limit 35 V
