1 Technical Description
1.6 Technical Data
1.6.3 Technical Data of the Options Modules
SIP ART DR24 6DR2410
C79000-G7476-C153-03
103
6DR2802--8B 3AA and 3BE Analog outputs AA7 to AA9, digital inputs BE5 to BE7
(slot 5);
Analog outputs AA4 to AA6 (slot 6), digital inputs BE10 to
BE12 (slot 5);
- Analog outputs
Rated signal range (0 to 100 %) 0 to 20 mA or 4 mA to 20 mA
Dynamic range 0 to 20.5 mA or 3.8 mA to 20.5 mA
Load range from --1 V to 18 V
No load voltage ≤26 V
Inductive load ≤0.1 H
T ime constant 10 ms
Residual ripple 900 Hz ≤0.2 %
Resolution 10 bits
Load dependence ≤0.1 %
Zero point error ≤0.3 %
End value error ≤0.3 %
Linearity ≤0.05 %
Temperature influence
Zero point ≤0.1%/10K
End value ≤0.1%/10K
Static destruction limit --1 V to 35 V
- Digital inputs
Signal status 0 ≤ 4.5 V or open
Signal status 1 ≥ 13 V
Input resistance ≥27 kΩ
Static destruction limit 35 V
6DR2803-8P PROFIBUS--DP
T ransmittable signals RS 485, PROFIBUS-DP protocol
T ransmittable data Operating state, process variables, parameters
and configuring switches
T ransmission procedure
PROFIBUS-/DP protocol According to DIN 19245, part 1 and part 3 (EN 50170)
T ransmission speed 9.6 kBit/s to 1.5 MBit/s
Station number 0 to 125
T ime monitor of the data communication Can be configuring on the controller in connection
with the DP--watchdog
Electrical isolation between
Rxd/Txd-P/-N and the controller 50 V UC common mode voltage
Test voltage 500 V AC
Repeater control signal CNTR-P TTL level with 1 TTL load
Power supply VP (5 V) 5 V -0.4 V/+0.2 V; short--circuit proof
Line lengths; per segment at 1.5 MBit/s 200 m; see ET200 6ES5 998-3ES12 manual for fur-
ther data
