1 Technical Description
1.6 Technical Data
1.6.3 Technical Data of the Options Modules
Manual
106
SIP ART DR24 6DR2410
C79000-G7476-C153-03
3
2
1
8
7
NS 35/15
Center of the
mounting rail
1218
9
139
136
100
130
36
131.5
39
66
NS 32
NS 35/7.5
6
5
4
Figure 1--44 Dimensioned diagram coupling relay, dimensions in mm
