9 List of Abbreviations Manual
266
SIP ART DR24 6DR2410
C79000-G7476-C153-03
yA Manipulated variable start
ya Automatic manipulated variable
ya Manipulated variable in non--automatic mode
YBL Blocking signal for manipulated variable
yE Manipulated variable full scale
YES yes
yI(t) I-part of the manipulated variable at time t
yI|
t=0
Working point of the I-partattimet=0
Yo Working point P--controller (manipulated variable)
YH Manual manipulated variable
y
L
Last manipulated variable before power failure
YN Tracking variable
y
p
P-part of the manipulated variable
YR Position feedback variable
YZ Disturbance variable to the output (manipulated variable)
Δw incremental w--adjustment
Δy incremental y adjustment
0MA 0 mA, constant current
4MA 4 mA, constant current
50H 50 Hz Frequency suppression
60H 60 Hz Frequency suppression
5BE Option module 5 digital inputs
4BA Option module 4 digital inputs
2rEL Option module 2 relays
3AE Option module 3 analog inputs
1AA Option module 1 analog output (yHold)
*.n New parameter
*.o Old parameter
Fault
