1 Technical Description

1.5 Functional Description

1.5.2 Input Functions

SIP ART DR24 6DR2410

C79000-G7476-C153-03

Data sinks bLS, bLPS, bLb

These sinks serve to block operation (bLb), the parameter and configuration adjustment (bLPS)

or just the configuration adjustment (bLS). At bLPS = high an error message no(dd1) PS(dd3) is

displayed when attempting to enter the parameterization mode.

At bLS = high no error message appears but the StrU level in the parameterization preselection

is hidden. The sinks bLS, bLPS and bLB can only be switched by the binary inputs BE1 to

BE14 (bE** = source) and the SES sources SbE1 to SbE8. When the CB time monitor re-

sponds or at Cbt = oFF, the SES sources connected with bLS, bLPS or bLb are set to low. See

also chapter 3.3.7, table 3--8, page 157.

The factory setting is low.

Keys tA1 to tA7

The keys (see figure 1--9, page 28) are available as key function tA*.1, tA*.2 or as switching

functions tA*.3, tA*.4 or tA*.5, tA*.6 (see figure 1--8, page 28). The keys are provided primarily

for incremental adjustment of the complex functions „Integrator with digital input” (bin) or con-

troller inputsΔy. They can be switched by the control inputs tA*U/tA*M for quadruple applica-

tions whereby the status of the switched off outputs Q and Q

remains unchanged.

The key tA5 has no key output to other operating levels because of the universal function; i.e.

tA5.1 and possibly tA5.2 are not available. The outputs Q and Q

are switched at key 5 with the

low edge (release the key). “PS” flashes in dd3 after pressing tA5 continuously for about 5 s. All

keys lose their function in the process operating level when the display flashes in dd3.

You can now switch to the other levels (parametering, configuring). See chapter 3.3.1 (page

136), 3.3.2 (page 138) and 3.3, page 135.

When the function tA*.U is assigned „no” in the configuring mode hdEF, the shaded data

sources and sinks do not appear in the configuring mode FCon. Since the sink tA*.U is pre--as-

signed with low, the drawn switch position is active.

Restart conditions

Power on Q

bAtt = no

bAtt = YES

last status
