Manual

1 Technical Description

1.5 Functional Description

1.5.8 Complex Functions (Arithmetic blocks c, d, h)

SIP ART DR24 6DR2410

C79000-G7476-C153-03

- Source for the program preselection d*.05

AT d*.05 = Low preslection is made through the inputs d*.06 to d*.12, at d*.05 = High the

preselection is made through the serial interface SES (Status SI--CLOCK).

- Program preselection d*.06 to d*.12

Program preselection through digital inputs, at d*.05 = Low:

d*.06 to d*.12 determine the program according to the following table:

d*.12 d*.11 d*.10 d*.09 d*.08 d*.07 d*.06 Program

The preselection inputs must have reached the desired level before start or reset. Level

changes during the program run have no influence. If more than one input d*.06 to d*.12

has Hi level or the selected program n is not defined (CLPr = no.n), the clock does not

start with the start edge. If d*.3A (interval display) is switched with dd3, no.n is displayed

after start or reset in this error case. The error must be cleared and the program re-

started.

D Outputs d*.1A to d*.14.(A)

- d*.1A Time from start 1st interval of a program

Only for direct connection with dd1.1 to dd2.2. Only these connections are permitted in

the FCon mode. The private parameters of the displays are not effective. The time in h,

min from the start of the 1st interval is displayed. At 23.59 the clock switches to 00.00. It

is reset by Reset (d*.03), see under Reset d*.03.

- d*.2A Time in interval

Only for direct connection with dd1.1 to dd2.2. Only these connections are permitted in

the FCon mode. The private parameters of the displays are not effective. The time in the

currently running interval is displayed in min, sec or h, min depending on CLFo.

- d*.3A interval

Only for direct connection with dd3.1 and dd3.2. Only these connections are permitted in

the FCon mode. The private parameters of dd3 are not effective.

The current interval xx and the running program n in the form xx.n are displayed.

The display of the interval is retained until the appropriate interval has run out.

-d*.4AClockStop

The output is always high when the clock stops. This is the case after Stop, Reset,

Power on (with batt = no.), manual reset and at the end of the program cycle.

- d*.5A, d*.6A Analog outputs A1, A2

Outputs of the analog values A1 (d*.5A) and A2 (d*.6A), which are assigned to the inter-

vals (see CLA1, CLA2).
