Voltage-Comparison Supervision
Times
Alarm times
Approx. 3 ms to 12 ms + OOT
68
at 50 Hz
Approx. 2.5 ms to 10 ms + OOT at 60 Hz
Dropout time 20 ms
Frequency Operating Range
10 Hz ≤ f ≤ 80 Hz According to specified tolerances
f < 10 Hz Inactive
f > 80 Hz
Tolerances
Pickup threshold
Voltage 0.5 % of the setting value or 0.05 V
12.21
68
OOT (Output Operating Time): extra delay of the output medium used
Technical Data
12.21 Voltage-Comparison Supervision
766 SIPROTEC 5, Paralleling Device, Manual
C53000-H5040-C071-1, Edition 05.2018
