Arc Protection
Setting Values
Threshold I> 1 A @ 100 Irated 0.030 A to 35.000 A Increments of 0.001 A
5 A @ 100 Irated 0.15 A to 175.00 A Increments of 0.01 A
1 A @ 1.6 Irated 0.001 A to 1.600 A Increments of 0.001 A
5 A @ 1.6 Irated 0.005 A to 8.000 A Increments of 0.001 A
Threshold 3I0>> 1 A @ 100 Irated 0.030 A to 35.000 A Increments of 0.001 A
5 A @ 100 Irated 0.15 A to 175.00 A Increments of 0.01 A
1 A @ 1.6 Irated 0.001 A to 1.600 A Increments of 0.001 A
5 A @ 1.6 Irated 0.005 A to 8.000 A Increments of 0.001 A
External trip initiation no
current
light
Operating mode light only
current and light
Sensor point sensor
line sensor
custom
Threshold light -28.00 dB to 0.00 dB Increments of 0.01
Channel Possible settings, application-dependent
Dropout
The larger dropout differential (= | pickup threshold – dropout threshold |) of the following
2 criteria is used:
Dropout differential derived from the
Dropout ratio parameter
If this parameter is not available, a dropout ratio of 95 % applies to the overcurrent protection and a dropout
ratio of 105 % applies to the undercurrent protection.
Minimum absolute dropout differential
Protection-class current transformers 15 mA sec. (I
rated
= 1 A) or
75 mA sec. (I
rated
= 5 A)
Instrument transformers 0.5 mA sec. (I
rated
= 1 A) or
2.5 mA sec. (I
rated
= 5 A)
Times
Shortest operate time
Operating mode = light only
Approx. 2.6 ms + OOT
69
Shortest operate time
Operating mode = Current and light
Approx. 4.0 ms + OOT at 50 Hz
Approx. 3.8 ms + OOT at 60 Hz
12.22
69
OOT (Output Operating Time): Additional delay of the output medium used, for example, 5 ms with fast relay, see chapter 12.1.4 Relay
Outputs
Technical Data
12.22 Arc Protection
SIPROTEC 5, Paralleling Device, Manual 767
C53000-H5040-C071-1, Edition 05.2018
