2 Functions
102
7UT613/63x Manual
C53000-G1176-C160-2
311 FaultConfig/Set OUT Fault in configuration / setting
312 GenErrGroupConn OUT Gen.err.: Inconsistency group/connection
313 GenErrEarthCT OUT Gen.err.: Sev. earth-CTs with equal typ
314 GenErrSidesMeas OUT Gen.err.: Number of sides / measurements
501 Relay PICKUP OUT Relay PICKUP
511 Relay TRIP OUT Relay GENERAL TRIP command
545 PU Time VI Time from Pickup to drop out
546 TRIP Time VI Time from Pickup to TRIP
576 IL1S1: VI Primary fault current IL1 side1
577 IL2S1: VI Primary fault current IL2 side1
578 IL3S1: VI Primary fault current IL3 side1
579 IL1S2: VI Primary fault current IL1 side2
580 IL2S2: VI Primary fault current IL2 side2
581 IL3S2: VI Primary fault current IL3 side2
582 I1: VI Primary fault current I1
583 I2: VI Primary fault current I2
584 I3: VI Primary fault current I3
585 I4: VI Primary fault current I4
586 I5: VI Primary fault current I5
587 I6: VI Primary fault current I6
588 I7: VI Primary fault current I7
30060 Gen CT-M1: VI General: Adaption factor CT M1
30061 Gen CT-M2: VI General: Adaption factor CT M2
30062 Gen CT-M3: VI General: Adaption factor CT M3
30063 Gen CT-M4: VI General: Adaption factor CT M4
30064 Gen CT-M5: VI General: Adaption factor CT M5
30065 Gen VT-U1: VI General: Adaption factor VT UL123
30067 par too low: VI parameter too low:
30068 par too high: VI parameter too high:
30069 settingFault: VI setting fault:
30070 Man.Clos.Det.M1 OUT Manual close signal meas.loc. 1 detected
30071 Man.Clos.Det.M2 OUT Manual close signal meas.loc. 2 detected
30072 Man.Clos.Det.M3 OUT Manual close signal meas.loc. 3 detected
30073 Man.Clos.Det.M4 OUT Manual close signal meas.loc. 4 detected
30074 Man.Clos.Det.M5 OUT Manual close signal meas.loc. 5 detected
30075 Man.Clos.Det.S1 OUT Manual close signal side 1 is detected
30076 Man.Clos.Det.S2 OUT Manual close signal side 2 is detected
30077 Man.Clos.Det.S3 OUT Manual close signal side 3 is detected
30078 Man.Clos.Det.S4 OUT Manual close signal side 4 is detected
30079 Man.Clos.Det.S5 OUT Manual close signal side 5 is detected
30251 IL1M1: VI Primary fault current IL1 meas. loc. 1
30252 IL2M1: VI Primary fault current IL2 meas. loc. 1
30253 IL3M1: VI Primary fault current IL3 meas. loc. 1
30254 IL1M2: VI Primary fault current IL1 meas. loc. 2
30255 IL2M2: VI Primary fault current IL2 meas. loc. 2
30256 IL3M2: VI Primary fault current IL3 meas. loc. 2
No. Information Type of In-
formation
Comments
