2.1 General
35
7UT613/63x Manual
C53000-G1176-C160-2
2.1.2 EN100-Modul 1
2.1.2.1 Function Description
An EN100-Modul 1 allows to integrate the 7UT613/63x into 100 Mbit Ethernet com-
munication networks used by process control and automation systems and running
IEC 61850 protocols. This standard provides consistent inter-relay communication
without gateways or protocol converters. This allows open and interoperable use of
SIPROTEC 4 devices even in heterogeneous environments. In parallel to the process
control integration of the device, this interface can also be used for communication
with DIGSI and for inter-relay communication via GOOSE.
2.1.2.2 Setting Notes
Interface Selection No settings are required for operation of the Ethernet system interface module
(IEC 61850, EN100-Modul 1). If the device is equipped with such a module (see
MLFB), the module is automatically configured to the interface available for it, namely
Port B.
5 >Reset LED SP >Reset LED
15 >Test mode SP >Test mode
16 >DataStop SP >Stop data transmission
51 Device OK OUT Device is Operational and Protecting
52 ProtActive IntSP At Least 1 Protection Funct. is Active
55 Reset Device OUT Reset Device
56 Initial Start OUT Initial Start of Device
67 Resume OUT Resume
69 DayLightSavTime OUT Daylight Saving Time
70 Settings Calc. OUT Setting calculation is running
71 Settings Check OUT Settings Check
72 Level-2 change OUT Level-2 change
73 Local change OUT Local setting change
109 Frequ. o.o.r. OUT Frequency out of range
125 Chatter ON OUT Chatter ON
320 Warn Mem. Data OUT Warn: Limit of Memory Data exceeded
321 Warn Mem. Para. OUT Warn: Limit of Memory Parameter exceeded
322 Warn Mem. Oper. OUT Warn: Limit of Memory Operation exceeded
323 Warn Mem. New OUT Warn: Limit of Memory New exceeded
No. Information Type of In-
formation
Comments
