2 Functions
308
7UT613/63x Manual
C53000-G1176-C160-2
630 U2 = MV U2 (negative sequence)
641 P = MV P (active power)
642 Q = MV Q (reactive power)
644 Freq= MV Frequency
645 S = MV S (apparent power)
721 IL1S1= MV Operat. meas. current IL1 side 1
722 IL2S1= MV Operat. meas. current IL2 side 1
723 IL3S1= MV Operat. meas. current IL3 side 1
724 IL1S2= MV Operat. meas. current IL1 side 2
725 IL2S2= MV Operat. meas. current IL2 side 2
726 IL3S2= MV Operat. meas. current IL3 side 2
727 IL1S3= MV Operat. meas. current IL1 side 3
728 IL2S3= MV Operat. meas. current IL2 side 3
729 IL3S3= MV Operat. meas. current IL3 side 3
765 U/f = MV (U/Un) / (f/fn)
901 PF = MV Power Factor
30633 ϕI1= MV Phase angle of current I1
30634 ϕI2= MV Phase angle of current I2
30635 ϕI3= MV Phase angle of current I3
30636 ϕI4= MV Phase angle of current I4
30637 ϕI5= MV Phase angle of current I5
30638 ϕI6= MV Phase angle of current I6
30639 ϕI7= MV Phase angle of current I7
30640 3I0S1= MV 3I0 (zero sequence) of side 1
30641 I1S1= MV I1 (positive sequence) of side 1
30642 I2S1= MV I2 (negative sequence) of side 1
30643 3I0S2= MV 3I0 (zero sequence) of side 2
30644 I1S2= MV I1 (positive sequence) of side 2
30645 I2S2= MV I2 (negative sequence) of side 2
30646 I1= MV Operat. meas. current I1
30647 I2= MV Operat. meas. current I2
30648 I3= MV Operat. meas. current I3
30649 I4= MV Operat. meas. current I4
30650 I5= MV Operat. meas. current I5
30651 I6= MV Operat. meas. current I6
30652 I7= MV Operat. meas. current I7
30653 I8= MV Operat. meas. current I8
30656 Umeas.= MVU Operat. meas. voltage Umeas.
30661 IL1M1= MV Operat. meas. current IL1 meas. loc. 1
30662 IL2M1= MV Operat. meas. current IL2 meas. loc. 1
30663 IL3M1= MV Operat. meas. current IL3 meas. loc. 1
30664 3I0M1= MV 3I0 (zero sequence) of meas. loc. 1
30665 I1M1= MV I1 (positive sequence) of meas. loc. 1
30666 I2M1= MV I2 (negative sequence) of meas. loc. 1
30667 IL1M2= MV Operat. meas. current IL1 meas. loc. 2
30668 IL2M2= MV Operat. meas. current IL2 meas. loc. 2
No. Information Type of In-
formation
Comments
