Siemens SIPROTEC 7UT635*-* N series User Manual

3 Mounting and Commissioning
386
7UT613/63x Manual
C53000-G1176-C160-2
Table 3-24 Indications on inconsistencies
Message No Meaning see
Section
„Error1A/5Awrong“ 192 Setting of the rated secondary currents on input/output board incon-
sistent, general
2.1.4
3.1.2 („Switch ele-
ments on printed
circuit boards“)
„Err. IN CT M1“
to
„Err. IN CT M5“
30097
to
30101
Setting of the rated secondary currents inconsistent for the indicated
measured current input (3-phase inputs)
2.1.4
3.1.2 („Switch ele-
ments on printed
circuit boards“)
„Err.IN CT1..3“
to
„Err.IN CT10..12“
30102
to
30105
Setting of the rated secondary currents inconsistent for the indicated
measured current input (inputs for single-phase busbar protection)
2.1.4
3.1.2 („Switch ele-
ments on printed
circuit boards“)
„Err. IN CT IX1“
to
„Err. IN CT IX4“
30106
to
30109
Setting of the rated secondary currents inconsistent for the indicated
measured current input (single-phase inputs)
2.1.4
3.1.2 („Switch ele-
ments on printed
circuit boards“)
„FaultConfig/Set“ 311 Group indication for configuration error
„GenErrGroupConn“ 312 General: Error in transformer connection group 2.1.4
„GenErrEarthCT“ 313 Error in single-phase inputs for earth fault differential protection 2.1.4
„GenErrSidesMeas“ 314 Error in assignment of sides and/or measuring locations 2.1.4
„par too low:“ 30067 Parameter setting value too small for the indicated address number
„par too high:“ 30068 Parameter setting value too high for the indicated address number
„settingFault:“ 30069 Parameter setting implausible for the indicated address number
„Diff Adap.fact.“ 5620 The matching factor of the current transformers for the differential
protection is too great or too small
2.1.4
2.2
„Diff err. Set.“ 5623 Differential protection setting not plausible 2.2
REF not avail. 5835 Restricted earth fault protection is not available for the configured
protected object
2.1.4
REF Adap.fact. 5836 The matching factor of the current transformers for restricted earth
fault protection is too great or too small.
2.1.4
2.3
REF Err CTstar 5830 There is no single-phase measuring input assigned to the starpoint
current for restricted earth fault protection
2.1.4
2.2
„REF err. Set.“ 199.2493 Earth fault differential protection setting not plausible 2.1.1
„REF2 Not avail.“ 205.2491 Restricted earth fault protection 2 is not available for the configured
protected object
2.4.1
„REF2 Adap.fact.“ 205.2494 The matching factor of the current transformers for restricted earth
fault protection 2 is too great or too small.
2.4.1
2.3
„REF2 Err CTstar“ 205.2492 There is no single-phase measuring input assigned to the starpoint
current for restricted earth fault protection 2
2.4.1
2.2
„REF2 err. Set.“ 205.2493 Earth fault differential protection setting not plausible 2.1.1
O/C Ph. not active 1860 Time overcurrent protection for phase currents is not available for the
configured protected object
2.1.4
„O/C Para error“ 023.2493 Settings for time overcurrent protection for phase currents not plausi-
ble
2.4.2
„O/C Ph2 Not av.“ 207.2491 Time overcurrent protection for phase currents 2 is not available for
the configured protected object
2.1.42.1.6
„O/C Ph2 err Set“ 207.2493 Settings for time overcurrent protection for phase currents 2 not plau-
sible
2.4.2
