4.1 General
427
7UT613/63x Manual
C53000-G1176-C160-2
Optical fibre (FO)
ST connector
FOC connector type
Connection for flush mounted
case
Rear panel, mounting location
„B“
Connection for surface
mounted case
in the inclined housing on the
case bottom
Optical wavelength λ = 820 nm
Laser class 1 according to EN
60825-1/-2
Using glass fibre 50/12 µm or
using glass fibre 62.5/125 µm
Permissible optical signal at-
tenuation
max. 8 dB using glass fibre
62.5/125 µm
Maximum bridgeable
distance
1.5 km
Character idle state Selectable: factory setting
„Light off“
PROFIBUS RS485
(FMS and DP)
rear panel, mounting loca-
tion „B“,
9-pole DSUB miniature
socket
Connection for flush-mounted housing
Connection for surface
mounted case
in the inclined housing on the
case bottom
Test voltage 500 V; 50 Hz
Transmission speed up to 1.5 MBd
Maximum bridgeable
distance
1,000 m (3300 ft) at ≤
93.75 kBd
500 m (1640 ft) at ≤ 187.5 kBd
200 m (660 ft) at ≤ 1.5 MBd
PROFIBUS FOC
(FMS and DP)
ST connector
with FMS: Single or double
ring according to order;
with DP: only double ring
available
FOC connector type
Connection for flush mounted
case
only with external OLM;
rear panel, mounting location
„B“
Connection for surface
mounted case
only with external OLM;
in the inclined housing on the
case bottom
Transmission speed
— recommended:
up to 1.5 MBd
> 500 kBd
Optical wavelength λ = 820 nm
Laser class 1 acc. to
EN 60825-1/-2
Using glass fibre 50/125 µm or
using glass fibre 62.5/125 µm
Permissible optical signal at-
tenuation
max. 8 dB, with glass fibre
62.5/125 µm
maximum bridgeable distance
between two modules at redun-
dant optical ring topology and
optical fibre 62.5/125 m
approx. 1.6 km (1750 ft) at
500 kbit/s
approx. 530 m (1750 ft) at
1500 kbit/s
DNP3.0 RS485
rear panel, mounting loca-
tion „B“,
9-pole DSUB miniature
socket
Connection for flush-mounted housing
Connection for surface
mounted case
in the inclined housing on the
case bottom
Test voltage 500 V; 50 Hz
Transmission speed up to 19,200 Baud
Maximum bridgeable
distance
1 km
