A Appendix
554
7UT613/63x Manual
C53000-G1176-C160-2
0 Pick-up thresh. Flx 0.01 .. 17.00 Q/SnS 1.10 Q/SnS Pick-up threshold Q-side
0 P.U. THRESHOLD Flx -0.99 .. 0.99 0.50 Pickup Threshold
0 T TRIP DELAY Flx 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY Flx 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY Flx 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLOCKED BY FFM Flx YES
NO
YES Block in case of Meas.-Voltage
Loss
0A Blk I brkn cond Flx YES
NO
YES Block for broken conductor in CT
path
0A DROPOUT RATIO Flx 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO Flx 1.01 .. 3.00 1.05 Dropout Ratio
0 Function addMV MinMax
Dmd
Min/Max/Dmd
Dmd+MiMaD
MiMa/Dmd+MiMaD
MinMax Scope of the extended measur-
ing values
0 Input Meas. Val addMV (Setting options depend
on configuration)
None Input measured value
0 Reset Meas. Val addMV (Setting options depend
on configuration)
>Reset MinMax Reset of ext. meas. values in
progress
201 FltDisp.LED/LCD Device Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
202 Spont. FltDisp. Device NO
YES
NO Spontaneous display of flt.an-
nunciations
204 Start image DD Device image 1
image 2
image 3
image 4
image 5
image 6
image 7
image 1 Start image Default Display
211 No Conn.MeasLoc P.System Data 1 2
3
4
5
3 Number of connected Measuring
Locations
212 No AssigMeasLoc P.System Data 1 2
3
4
5
3 Number of assigned Measuring
Locations
213 NUMBER OF SIDES P.System Data 1 2
3
4
5
3 Number of Sides
216 NUMBER OF ENDS P.System Data 1 3
4
5
6
7
8
9
10
11
12
6 Number of Ends for 1 Phase
Busbar
220 ASSIGNM. 2M,2S P.System Data 1 M1,M2 M1,M2 Assignment at 2 as-
sig.Meas.Loc./ 2 Sides
221 ASSIGNM. 3M,2S P.System Data 1 M1+M2,M3
M1,M2+M3
M1+M2,M3 Assignment at 3 as-
sig.Meas.Loc./ 2 Sides
222 ASSIGNM. 3M,3S P.System Data 1 M1,M2,M3 M1,M2,M3 Assignment at 3 as-
sig.Meas.Loc./ 3 Sides
223 ASSIGNM. 4M,2S P.System Data 1 M1+M2,M3+M4
M1+M2+M3,M4
M1,M2+M3+M4
M1+M2,M3+M4 Assignment at 4 as-
sig.Meas.Loc./ 2 Sides
224 ASSIGNM. 4M,3S P.System Data 1 M1+M2,M3,M4
M1,M2+M3,M4
M1,M2,M3+M4
M1+M2,M3,M4 Assignment at 4 as-
sig.Meas.Loc./ 3 Sides
225 ASSIGNM. 4M,4S P.System Data 1 M1,M2,M3,M4 M1,M2,M3,M4 Assignment at 4 as-
sig.Meas.Loc./ 4 Sides
Addr. Parameter Function C Setting Options Default Setting Comments
