A.8 Settings
559
7UT613/63x Manual
C53000-G1176-C160-2
424 DMT/IDMT E AT P.System Data 1 no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT / IDMT Earth assigned to
427 DMT 1PHASE AT P.System Data 1 no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT 1Phase assigned to
430 DMT/IDMT Ph2 AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 2 assigned to
432 DMT/IDMT Ph3 AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 3 assigned to
434 DMT/IDMT3I0-2AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 2 assigned to
436 DMT/IDMT3I0-3AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 3 assigned to
438 DMT/IDMT E2 AT P.System Data 1 no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT / IDMT Earth 2 assigned to
440 UNBAL. LOAD AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 Unbalance Load (Neg. Seq.) as-
signed to
442 THERM. O/L AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Side 1 Thermal Overload Protection as-
signed to
444 THERM. O/L 2 AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Side 1 Thermal Overload Protection2
assigned to
Addr. Parameter Function C Setting Options Default Setting Comments
