A Appendix
562
7UT613/63x Manual
C53000-G1176-C160-2
723 IN-SEC CT IX2 P.System Data 1 1A
5A
1A CT rated secondary current IX2
731 EARTH IX3 AT P.System Data 1 Terminal R7
Terminal R8
Terminal R7 Earthing electrod IX3 connected
to
732 IN-PRI CT IX3 P.System Data 1 1 .. 100000 A 200 A CT rated primary current IX3
733 IN-SEC CT IX3 P.System Data 1 1A
5A
1A CT rated secondary current IX3
734 FACTOR CT IX3 P.System Data 1 1.0 .. 300.0 60.0 Factor: prim. over sek. current
IX3
741 EARTH IX4 AT P.System Data 1 Terminal P7
Terminal P8
Terminal P7 Earthing electrod IX4 connected
to
742 IN-PRI CT IX4 P.System Data 1 1 .. 100000 A 200 A CT rated primary current IX4
743 IN-SEC CT IX4 P.System Data 1 1A
5A
1A CT rated secondary current IX4
744 FACTOR CT IX4 P.System Data 1 1.0 .. 300.0 60.0 Factor: prim. over sek. current
IX4
801 UN-PRI VT SET P.System Data 1 1.0 .. 1200.0 kV 110.0 kV VT Rated Prim. Voltage Set UL1,
UL2, UL3
802 UN-SEC VT SET P.System Data 1 80 .. 125 V 100 V VT Rated Sec. Voltage Set UL1,
UL2, UL3
803 CORRECT. U Ang P.System Data 1 -5.00 .. 5.00 ° 0.00 ° Angle correction UL1, UL2, UL3 -
VT
811 UN-PRI VT U4 P.System Data 1 1.0 .. 1200.0 kV 110.0 kV VT Rated Primary Voltage U4
812 UN-SEC VT U4 P.System Data 1 80 .. 125 V 100 V VT Rated Secondary Voltage U4
816 Uph / Udelta P.System Data 1 0.10 .. 9.99 1.73 Matching ratio Phase-VT to
Open-Delta-VT
817 Uph(U4)/Udelta P.System Data 1 0.10 .. 9.99 1.73 Matching ratio Ph-VT(U4) to
Open-DeltaVT
831 SwitchgCBaux S1 P.System Data 1 (Setting options depend
on configuration)
Q0 Switchgear / CBaux at Side 1
832 SwitchgCBaux S2 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 2
833 SwitchgCBaux S3 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 3
834 SwitchgCBaux S4 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 4
835 SwitchgCBaux S5 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 5
836 SwitchgCBaux M1 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Measur-
ing Loc. M1
837 SwitchgCBaux M2 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Measur-
ing Loc. M2
838 SwitchgCBaux M3 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Measur-
ing Loc. M3
839 SwitchgCBaux M4 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Measur-
ing Loc. M4
840 SwitchgCBaux M5 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at Measur-
ing Loc. M5
841 SwitchgCBaux E1 P.System Data 1 (Setting options depend
on configuration)
None Switchgear / CBaux at ext. loca-
tion 1
851A TMin TRIP CMD P.System Data 1 0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command Dura-
tion
901 WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
903 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 1.00 sec Max. length of a Waveform
Capture Record
904 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform Prior to
Trigger
905 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
906 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
1107 P,Q sign P.System Data 2 not reversed
reversed
not reversed sign of P,Q
Addr. Parameter Function C Setting Options Default Setting Comments
