Siemens SIPROTEC 7UT635*-* N series User Manual

A Appendix
608
7UT613/63x Manual
C53000-G1176-C160-2
30063 General: Adaption factor CT M4
(Gen CT-M4:)
P.System Data 2 VI ON
OFF
30064 General: Adaption factor CT M5
(Gen CT-M5:)
P.System Data 2 VI ON
OFF
30065 General: Adaption factor VT
UL123 (Gen VT-U1:)
P.System Data 2 VI ON
OFF
30067 parameter too low: (par too low:) P.System Data 2 VI ON
OFF
30068 parameter too high: (par too
high:)
P.System Data 2 VI ON
OFF
30069 setting fault: (settingFault:) P.System Data 2 VI ON
OFF
30070 Manual close signal meas.loc. 1
detected (Man.Clos.Det.M1)
P.System Data 2 OUT ON * * LED BO
30071 Manual close signal meas.loc. 2
detected (Man.Clos.Det.M2)
P.System Data 2 OUT ON * * LED BO
30072 Manual close signal meas.loc. 3
detected (Man.Clos.Det.M3)
P.System Data 2 OUT ON * * LED BO
30073 Manual close signal meas.loc. 4
detected (Man.Clos.Det.M4)
P.System Data 2 OUT ON * * LED BO
30074 Manual close signal meas.loc. 5
detected (Man.Clos.Det.M5)
P.System Data 2 OUT ON * * LED BO
30075 Manual close signal side 1 is de-
tected (Man.Clos.Det.S1)
P.System Data 2 OUT ON * * LED BO
30076 Manual close signal side 2 is de-
tected (Man.Clos.Det.S2)
P.System Data 2 OUT ON * * LED BO
30077 Manual close signal side 3 is de-
tected (Man.Clos.Det.S3)
P.System Data 2 OUT ON * * LED BO
30078 Manual close signal side 4 is de-
tected (Man.Clos.Det.S4)
P.System Data 2 OUT ON * * LED BO
30079 Manual close signal side 5 is de-
tected (Man.Clos.Det.S5)
P.System Data 2 OUT ON * * LED BO
30080 Measurment location 1 is discon-
nected (M1 disconnected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30081 Measurment location 2 is discon-
nected (M2 disconnected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30082 Measurment location 3 is discon-
nected (M3 disconnected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30083 Measurment location 4 is discon-
nected (M4 disconnected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30084 Measurment location 5 is discon-
nected (M5 disconnected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30085 End 1 is disconnected (I1 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30086 End 2 is disconnected (I2 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30087 End 3 is disconnected (I3 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30088 End 4 is disconnected (I4 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30089 End 5 is disconnected (I5 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30090 End 6 is disconnected (I6 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
30091 End 7 is disconnected (I7 discon-
nected)
Discon.MeasLoc OUT ON
OFF
**LEDBO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
