Siemens SIPROTEC 7UT635*-* N series User Manual

A Appendix
612
7UT613/63x Manual
C53000-G1176-C160-2
30354 >Manual close signal measure-
ment loc. 4 (>ManualClose M4)
P.System Data 2 SP * * * LED BI BO
30355 >Manual close signal measure-
ment loc. 5 (>ManualClose M5)
P.System Data 2 SP * * * LED BI BO
30356 >Manual close signal side 1
(>ManualClose S1)
P.System Data 2 SP * * * LED BI BO
30357 >Manual close signal side 2
(>ManualClose S2)
P.System Data 2 SP * * * LED BI BO
30358 >Manual close signal side 3
(>ManualClose S3)
P.System Data 2 SP * * * LED BI BO
30359 >Manual close signal side 4
(>ManualClose S4)
P.System Data 2 SP * * * LED BI BO
30360 >Manual close signal side 5
(>ManualClose S5)
P.System Data 2 SP * * * LED BI BO
30361 >disconnect without test: current
= 0 (>disconn. I>=0)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30362 >disconnect measurment loca-
tion 1 (>disconnect M1)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30363 >disconnect measurment loca-
tion 2 (>disconnect M2)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30364 >disconnect measurment loca-
tion 3 (>disconnect M3)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30365 >disconnect measurment loca-
tion 4 (>disconnect M4)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30366 >disconnect measurment loca-
tion 5 (>disconnect M5)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30367 >disconnect end 1 (>disconnect
I1)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30368 >disconnect end 2 (>disconnect
I2)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30369 >disconnect end 3 (>disconnect
I3)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30370 >disconnect end 4 (>disconnect
I4)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30371 >disconnect end 5 (>disconnect
I5)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30372 >disconnect end 6 (>disconnect
I6)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30373 >disconnect end 7 (>disconnect
I7)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30374 >disconnect end 8 (>disconnect
I8)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30375 >disconnect end 9 (>disconnect
I9)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30376 >disconnect end 10 (>disconnect
I10)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30377 >disconnect end 11 (>disconnect
I11)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30378 >disconnect end 12 (>disconnect
I12)
Discon.MeasLoc SP ON
OFF
**LEDBIBO
30607 Accumulation of interrupted curr.
L1 S1 (ΣIL1S1:)
Statistics VI
30608 Accumulation of interrupted curr.
L2 S1 (ΣIL2S1:)
Statistics VI
30609 Accumulation of interrupted curr.
L3 S1 (ΣIL3S1:)
Statistics VI
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
