Siemens SIPROTEC 7UT635*-* N series User Manual

2 Functions
90
7UT613/63x Manual
C53000-G1176-C160-2
396 PHASE SELECTION Phase 1
Phase 2
Phase 3
Phase 1 Phase selection
403 I PRIMARY OP M3 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 3
404 I PRIMARY OP M4 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 4
405 I PRIMARY OP M5 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 5
408 UN-PRI M3 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Measuring
Loc. 3
409 UN-PRI U4 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage U4
413 REF PROT. AT Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot. as-
signed to
414 REF PROT. 2 AT Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot2 as-
signed to
420 DMT/IDMT Ph AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase assigned to
422 DMT/IDMT 3I0 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 assigned to
Addr. Parameter Setting Options Default Setting Comments
