2.1 General
99
7UT613/63x Manual
C53000-G1176-C160-2
If parasitic currents (e.g. through induction) can be excluded when the circuit breaker
is open, these settings may normally be very sensitive. Otherwise the settings must
be increased correspondingly. In most cases the setting can be the same for all ad-
dresses displayed.
However, please note that current summation measuring errors may occur on the
sides which are fed by multiple measuring locations.
In the 1-phase busbar protection
, you can set such an open-pole current for each of
the up to 9 feeders (7UT613 and 7UT633 for 1-phase connection with or without sum-
mation CT) or 12 feeders (7UT635 with or without summation CT) of the busbar. The
maximum range of possible addresses includes:
Finally, it is also possible to monitor the residual currents at the auxiliary measuring
locations. These residual currents are needed by the dynamic cold-load pickup feature
of the earth overcurrent protection, if no side or measuring location is assigned to the
earth overcurrent protection. The maximum range of possible addresses includes:
Please remember to also allocate all binary inputs that are needed to generate a
manual close pulse for the various protection functions (FNos 30351 to 30360).
Note
In the following settings overview, the values are referred to the rated current of the
assigned side (I/I
NS
).
Address 1121 PoleOpenCurr.M1 for measuring location 1,
Address 1122 PoleOpenCurr.M2 for measuring location 2,
Address 1123 PoleOpenCurr.M3 for measuring location 3,
Address 1124 PoleOpenCurr.M4 for measuring location 4,
Address 1125 PoleOpenCurr.M5 for measuring location 5.
Address 1131 PoleOpenCurr I1 for feeder 1,
Address 1132 PoleOpenCurr I2 for feeder 2,
Address 1133 PoleOpenCurr I3 for feeder 3,
Address 1134 PoleOpenCurr I4 for feeder 4,
Address 1135 PoleOpenCurr I5 for feeder 5,
Address 1136 PoleOpenCurr I6 for feeder 6,
Address 1137 PoleOpenCurr I7 for feeder 7,
Address 1138 PoleOpenCurr I8 for feeder 8,
Address 1139 PoleOpenCurr I9 for feeder 9,
Address 1140 PoleOpenCurrI10 for feeder 10,
Address 1141 PoleOpenCurrI11 for feeder 11,
Address 1142 PoleOpenCurrI12 for feeder 12.
Address 1151 PoleOpenCurrIX1 for further measuring location 1,
Address 1152 PoleOpenCurrIX2 for further measuring location 2,
Address 1153 PoleOpenCurrIX3 for further measuring location 3,
Address 1154 PoleOpenCurrIX4 for further measuring location 4.
