Installation
5.1 Input side connection
Selectivity modules
42 Manual, 12.2014, C98130-A7579-A1-1-7629
The power supply is connected using input terminal ① with the designation "24 V" and the
0 V terminal
② with the designation "0 V"; the "0 V" connection is not for the load supply, but
is only to supply the internal electronics of the selectivity module (terminal cross-sections,
see Chapter Figure 2-2 Terminal data (Page 11)).
The "0 V" connection is only used to supply the internal electronics of the selectivity
module. The 0 V of the connected loads must be routed directly to the power supply using
separate cables!
