Documenting and
reporting
You can film images on a camera connected to your CT system. You
can also store the examination data (patient info, scan protocols,
and CT images) on DVD discs, USB devices, or a storage server in the
hospital network. After the examination data is reported and
archived, you may delete the data in the Patient Browser.
Filming
1 Click the Filming task card and then choose Patient > Browser
from the main menu.
2 In Patient Browser, double-click a series of images to load them
into the Filming task card.
3 Click the border of one film sheet to select all the images it
contains.
8
8.1
Documenting and reporting 8
SOMATOM Emotion | syngo CT VC50
Print No. HC-C2-025.626.01.01.02
71

Siemens SOMATOM Emotion Specifications

General

Type	CT Scanner
Gantry aperture	70 cm
Tube voltage	80, 110, 130 kV
Maximum scan range	200 cm
Maximum Scan Field of View	50 cm
Generator Power	32 kW
Image Matrix	512 x 512
Rotation time	0.8 s, 1.0 s, 1.5 s, 2.0 s (depending on configuration)
Patient weight capacity	200 kg
Table Weight Limit	200 kg
Image Reconstruction Time	Up to 8 images/second
